FX Luminaire SRPCHN Lighting Fixture - 9.9

The vibrant and versatile SRP RGBW Strip Light makes it easier than ever to illuminate stair ledges, outdoor patios, hardscape elements, and more. When installed with the SRP-CC Color Controller, the SRP RGBW Strip Light is compatible with the next-generation Luxor Controller from FX Luminaire or any traditional low-voltage transformer for unmatched color-changing effects. Choose from two convenient control options: Standalone or Luxor Mode. For compatibility with any low-voltage transformer, use Standalone Mode. It lets you manually set Hue, Saturation, and Intensity. Luxor Mode allows a Luxor Controller to assign a Group and set Hue, Saturation, and Intensity values. [](https://www.bigirrigation.com/wp-content/uploads/2022/10/beauty_shot_srp-rgbw_0_0.jpg)[SRP-CC Color Controller (order separately)](https://www.bigirrigation.com/lighting-supply/smart-controls/fx-luminaire-srp-cc-color-controller/) is required to power SRP RGBW Strip Light. See Accessories. #### Included Accessories & Parts SRP-10-RGBW Includes 3" (76 mm) and 6" (152 mm) jumpers, 10' power feed, splice clamps, LED spacer, end connector, and mounting clips.

[SRP RGBW Strip Light Dimensions](https://www.fxl.com/node/361381)

## [SRP RGBW Strip Light Specification Chart](https://www.fxl.com/node/359921) OutputSRP RGBWTotal Lumens24.25 lm/ftInput Voltage10 to 15 VInput Power1.7 W/ftVA2.9 VA/ftEfficacy (lm/W)18.6Color Rendering Index (CRI)52Center Beam Candlepower--DimmingYes; must use SRP-CC Color Controller Primary Dimming (Transformer)-- Secondary Dimming (Fixture)--RGBW AvailableYes; Must be used with SRP-CC Color ControllerMinimum Rated Life L90 B10 (Hrs)50,000 For optimal performance, use a trailing-edge (reverse phase-cut) dimmer.SRP RGBW Strip Light Illuminance at a DistanceDistanceCenter Beam fcBeam WidthFeet (Meters)Foot-Candles (Lux)Vertical: 115.7 °Horizontal: 115.5 °10.0' (3.1 m)2.9 fc (1.1 lx)10.5' (3.2 m)10.5' (3.2 m)20.0' (6.1 m)0.7 fc (0.3 lx)21.3' (6.5 m)21.2' (6.5 m)3.3' (1.0 m)0.3 fc (0.1 lx)31.8' (9.7 m)31.7' (9.7 m)6.7' (2.0 m)0.2 fc (0.1 lx)42.3' (12.9 m)42.2' (12.9 m)13.3' (4.1 m)0.1 fc (0 lx)53.1' (16.2 m)52.9' (16.1 m)16.7' (5.1 m)0.1 fc (0 lx)63.6' (19.4 m)63.6' (19.3 m)
